Sizes & Dimensions

Use the dimensions chart below to help you make the right choice for your client.
Want to make sure it fits? Download a detailed chair sizing worksheet.


Important: Make sure that seat width, depth and height are adequate for each individual user, and that the user’s weight does not exceed the maximum weight recommended.

Key user dimensions (inches)

A silhouette of a person with a line indicating their height measurement.

The user’s overall height is a general guide to help you select the appropriate size of HTS. Choose the model that allows for growth.

  • Basic Z110 small Rifton HTS includes seat, back, seatbelt and armrests.

    Small HTS Z110

    Z110

    Footboard angle adjustment (degrees):

    10°, 20° or 30° fwd,
    10° back

    Select View Dimensions
    Item Dimensions (inches)

    Overall height

    30 – 46

    (76 – 117 cm)

    Overall seat width (see also bases dimensions below)

    21½

    Tilt-in-space mobile base footprint

    21 x 27

    Tilt-in-space base length at full recline

    43

    Non-tilt base footprint

    20 x 25

    Seat (front) to footboard height*

    8½ – 13½

    Seat (front) to floor; mobile tilt frame

    15½ – 21½

    Seat (front) to floor; mobile non-tilt frame

    16 – 20

    Seat (front) to floor; stationary non-tilt frame

    13 – 17

    Seat depth (1" increments)

    8 / 9 / 10 / 11

    Seat width

    12
    with hip guides: 8 / 10

    Hole size in seat pad

    open 4 x 9
    closed 3 x 8

    Armrest height above seat

    5¼

    Backrest height above seat

    16½

    Backrest width

    11½

    Distance between laterals

    4¾ – 12

    Backrest angle adjustment (degrees)

    6° fwd, 6° and 18° back

    Tilt-in-space FORWARD **

    5°

    Tilt-in-space BACK **

    25°

    Full extention recline with headrest

    40.75

    Frame weight (lbs)

    15

    Maximum clearance height under seat (tilt frame)

    20½

    Maximum clearance height under seat (stationary non-tilt frame)

    15

    Maximum clearance height under seat (mobile non-tilt frame)

    18

    Portability base clearance (fits over ADA compliant toilets)

    18½

    Portability kit carry bag dimensions

    19½ high x 21¼ wide x 10 deep

    Bottom of frame to floor; tilt-in-space mobile base

    2

    Tub base footprint

    23 x 16½ at feet / 19 at top

    Tub base height

    11 at front x 9½ at back

    Maximum working load (lbs)

    75
  • Basic Z120 medium Rifton HTS includes seat, back, seatbelt and armrests.

    Medium HTS Z120

    Z120

    Footboard angle adjustment (degrees):

    10°, 20° or 30° fwd,
    10° back

    Select View Dimensions
    Item Dimensions (inches)

    Overall height

    42 – 56

    (106 – 142 cm)

    Overall seat width (see also bases dimensions below)

    21¼

    Tilt-in-space mobile base footprint

    21 x 27

    Tilt-in-space base length at full recline

    49¼

    Non-tilt base footprint

    20 x 25

    Seat (front) to footboard height*

    10½ – 15½

    Seat (front) to floor; mobile tilt frame

    15½ – 21½

    Seat (front) to floor; mobile non-tilt frame

    17 – 20½

    Seat (front) to floor; stationary non-tilt frame

    14 – 17½

    Seat depth (1" increments)

    11½ / 12½ / 13½ / 14½

    Seat width

    14
    with hip guides: 10 / 12
    with hip guides (thick pads): 8 / 10

    Hole size in seat pad

    open 4½ x 12
    closed 3½ x 10

    Armrest height above seat

    6½

    Backrest height above seat

    19½

    Backrest width

    13½

    Distance between laterals

    6¾ – 14½

    Backrest angle adjustment (degrees)

    6° fwd, 6° and 18° back

    Tilt-in-space FORWARD **

    5°

    Tilt-in-space BACK **

    25°

    Full extention recline with headrest

    46

    Frame weight (lbs)

    27½

    Maximum clearance height under seat (tilt frame)

    20½

    Maximum clearance height under seat (stationary non-tilt frame)

    15

    Maximum clearance height under seat (mobile non-tilt frame)

    18

    Portability base clearance (fits over ADA compliant toilets)

    18½

    Portability kit carry bag dimensions

    19½ high x 21¼ wide x 10 deep

    Bottom of frame to floor; tilt-in-space mobile base

    2

    Tub base footprint

    23 x 16½ at feet / 19 at top

    Tub base height

    11 at front x 9½ at back

    Maximum working load (lbs)

    150
  • Basic Z130 large Rifton HTS includes seat, back, seatbelt and armrests.

    Large HTS Z130

    Z130

    Overall height:

    50 – 74

    (127 – 188 cm)

    Select View Dimensions
    Item Dimensions (inches)

    Overall seat width (see also bases dimensions below)

    23½

    Tilt-in-space mobile base footprint

    23½ x 33

    Tilt-in-space base length at full recline

    57¼

    Non-tilt base footprint

    23½ x 29

    Seat (front) to footboard height*

    11¼ – 17½

    Distance between laterals

    10½ – 18

    Footboard angle adjustment (degrees)

    10°, 20° or 30° fwd,
    10° back

    Seat (front) to floor; mobile tilt frame

    17½ – 23

    Seat (front) to floor; mobile non-tilt frame

    18 – 22

    Seat (front) to floor; stationary non-tilt frame

    15 – 19

    Seat depth (1" increments)

    14½ / 15½ / 16½ / 17½

    Seat width

    17
    with hip guides: 13 / 15
    with hip guides (thick pads): 11 / 13

    Hole size in seat pad

    open 6 x 14
    closed 4½ x 12

    Armrest height above seat

    8

    Backrest height above seat

    24½

    Backrest width

    16

    Backrest angle adjustment (degrees)

    6° fwd, 6° and 18° back

    Tilt-in-space FORWARD **

    5°

    Tilt-in-space BACK **

    25°

    Full extention recline with headrest

    55.75

    Frame weight (lbs)

    45

    Maximum clearance height under seat (tilt frame)

    20¾

    Maximum clearance height under seat (stationary non-tilt frame)

    16½

    Maximum clearance height under seat (mobile non-tilt frame)

    19½

    Portability base clearance (fits over ADA compliant toilets)

    N/A

    Portability kit carry bag dimensions

    N/A

    Bottom of frame to floor; tilt-in-space mobile base

    2

    Tub base footprint

    N/A

    Tub base height

    N/A

    Maximum working load (lbs)

    250***
Key user dimensions (inches)
A silhouette of a person with a line indicating their height measurement.

The user’s overall height is a general guide to help you select the appropriate size of HTS. Choose the model that allows for growth.
Basic Z110 small Rifton HTS includes seat, back, seatbelt and armrests.

Small HTS Z110

(Z110)
Basic Z120 medium Rifton HTS includes seat, back, seatbelt and armrests.

Medium HTS Z120

(Z120)
Basic Z130 large Rifton HTS includes seat, back, seatbelt and armrests.

Large HTS Z130

(Z130)

Overall height

30 – 46

(76 – 117 cm)

42 – 56

(106 – 142 cm)

50 – 74

(127 – 188 cm)
Select
Select
Select
Item Dimensions (inches)

Tilt-in-space mobile base footprint

21 x 27

21 x 27

23½ x 33

Tilt-in-space base length at full recline

43

49¼

57¼

Non-tilt base footprint

20 x 25

20 x 25

23½ x 29

Seat (front) to footboard height*

8½ – 13½

10½ – 15½

11¼ – 17½

Seat (front) to floor; mobile tilt frame

15½ – 21½

15½ – 21½

17½ – 23

Seat (front) to floor; mobile non-tilt frame

16 – 20

17 – 20½

18 – 22

Seat (front) to floor; stationary non-tilt frame

13 – 17

14 – 17½

15 – 19

Seat depth (1" increments)

8 / 9 / 10 / 11

11½ / 12½ / 13½ / 14½

14½ / 15½ / 16½ / 17½

Seat width

12
with hip guides: 8 / 10

14
with hip guides: 10 / 12
with hip guides (thick pads): 8 / 10

17
with hip guides: 13 / 15
with hip guides (thick pads): 11 / 13

Hole size in seat pad

open 4 x 9
closed 3 x 8

open 4½ x 12
closed 3½ x 10

open 6 x 14
closed 4½ x 12

Armrest height above seat

5¼

6½

8

Backrest height above seat

16½

19½

24½

Backrest width

11½

13½

16

Distance between laterals

4¾ – 12

6¾ – 14½

10½ – 18

Tilt-in-space FORWARD **

5°

5°

5°

Tilt-in-space BACK **

25°

25°

25°

Backrest angle adjustment (degrees)

6° fwd, 6° and 18° back

6° fwd, 6° and 18° back

6° fwd, 6° and 18° back

Footboard angle adjustment (degrees)

10°, 20° or 30° fwd,
10° back

10°, 20° or 30° fwd,
10° back

10°, 20° or 30° fwd,
10° back

Maximum clearance height under seat (tilt frame)

20½

20½

20¾

Maximum clearance height under seat (stationary non-tilt frame)

15

15

16½

Maximum clearance height under seat (mobile non-tilt frame)

18

18

19½

Portability base clearance (fits over ADA compliant toilets)

18½

18½

N/A

Portability kit carry bag dimensions

19½ high x 21¼ wide x 10 deep

19½ high x 21¼ wide x 10 deep

N/A

Bottom of frame to floor; tilt-in-space mobile base

2

2

2

Tub base footprint

23 x 16½ at feet / 19 at top

23 x 16½ at feet / 19 at top

N/A

Tub base height

11 at front x 9½ at back

11 at front x 9½ at back

N/A

Maximum working load (lbs)

75

150

250***


HTS bases  Dimensions (inches)
 Z112 / Z122 (small/medium) tilt mobile base footprint
  21 wide x 27 long
 Z113 / Z123 (small/medium) non-tilt bases footprint
  20 wide x 25 long
 Z132 (large) tilt mobile base footprint
  22½ wide x 33 long
 Z133 (large) non-tilt base footprint
  21 wide x 29 long
 Z139 portability base
  21 wide x 16½ long



Without angle converter** With angle converter**
diagram showing the tilt of the Rifton HTS
 diagram showing the tilt of the Rifton HTS



*When the mobile base is in the lowest position and the footboard is fully extended, it may prevent the front casters from swiveling. In this case, either change the footboard angle or raise the seat height to give the casters room to swivel.


**To achieve 15˚ of forward tilt for ease of transfer, order the tilt angle converter, Z169 $47.00. (The range of adjustment will be 15˚ back and 15˚ forward. See reference charts above.)


***The maximum working load for the large HTS foot board is 150 lb.


More information about the HTS is located in its Product Manual.
